Dislocations of the Elbow

- Discussion:
    - see: elbow dislocations in children:
    - elbow dislocation is the second most common major joint dislocation;
    - dislocation is usually closed and posterior;
    - mechanism:
           - dislocations of elbow usually result from fall onto extended elbow.
           - anatomic morphology of semilunar notch may predispose to elbow dislocation;
           - central angle of semilunar notch is significantly larger in group of pts who had dislocation of the elbow compared to normals;
    - classification:
          - elbow dislocations without fracture are termed "simple." whereas dislocations with frx are termed complex
          - dislocations are classified according to direction of dislocation: posterior, posterolateral, posteromedial, lateral, medial,
                   or divergent;
          - ref: Posteromedial Elbow Dislocations w/o Osseous Lesions. Characteristics, Tissue Injury Patterns, Treatments, and Outcomes

          - simple dislocation: pathoanatomy:
                 - rupture of capsule, rupture of MCL, lateral ligaments, rupture of flexor pronator mass and less commonly, injury to
                            brachialis muscle;
                 - LCL may be the essential lesion in recurrent or persistent instability following simple dislocations of the elbow
                 - rupture of brachial artery has been reported;

          - complex dislocation:
                 - dislocation w/ radial head frx: most common complex dislocation;
                 - frx dislocation w/ MCL injury: radial head frx & MCL Instability:
                 - terrible Triad: (dislocation, cornoid process frx, and radial head frx)
                 - ref: Classification and evaluation of recurrent instability of the elbow.

    - stability of elbow:
          - primary stabilizers
                 - MCL is the main stabilizer of the elbow joint (provides 54% valgus stability, while osseous articulation provides 33%);
                 - ulnohumeral articulation
                         - coronoid: 50%  intact coronoid requirement for stability with or w/o ligamentous integrity
                         - olecranon contribution to stability inversely correlated with resection amount: >30% articular surface of olecranon
                                   needed for stability
          - secondary stabilizers
                - radiohumeral articulation (most important)
                - capsule: greatest role in extension of elbow, insignificant role (<10%) in flexion
                - musculature (dynamic)
                - ref: Articular and ligamentous contributions to the stability of the elbow joint

- Exam:
    - vascular injury:
         - closed dislocations are rarely assoc w/ vascular injury, whereas open &/or ant dislocations are commonly assoc w/ such injury;
         - in open dislocations, brachial artery is disrupted by forcible hyperextension (median nerve injury is commonly associated with
                 such injuries);
         - reference:
                 - Closed elbow dislocation and brachial artery damage.
                 - Occult closed posterior elbow dislocation with intimal rupture of the brachial artery in a 71-year-old male
    - neuro injury:
         - diff dx: compartment syndrome: before assuming that a nerve injury is present consider whether there is an evolving
                 compartment syndrome;
                 - remember that the pain of the compartment syndrome is distracted by the more obvious elbow dislocation;
                 - these patients often have had conscious sedation, which can blunt on going pain from a compartment syndrome;
                 - after several hours, the acute pain of a compartment syndrome may diminish (nerve ischemia), after which it will be
                           difficult to distinguish from a nerve injury;
         - neuropraxia is occurs in 20%, usually involving ulnar or median n (AIN branch);
         - ulnar nerve palsy may occur up to 14% of adult elbow dislocations, and the occurance of ulnar nerve palsy is much higher in
                 pediatric dislocations w/ an associated medial epicondyle frx;
         - most neurologic deficits are transient, but entrapment of median nerve w/ elbow joint after manipulation is more common in
                 pediatric dislocations;
         - reference:
                 - Median nerve palsy after posterolateral elbow dislocation.
    - bony displacement:
         - when nl elbow is extended, olecranon process & medial & lat form 3 points on straight line, & when nl elbow is flexed to 90 deg
                   in lateral view, olecranon is aligned vertically w/ epicondyles;
         - tip of the olecranon is, however, definitely posterior to the plane of the epicondyles;
         - in post dislocation, olecranon process is displaced backward from its normal position in relation to humerus, & one can palpate
                 the concavity of the semilunar notch;
         - increasing degree of elbow flexion exaggerates the prominence of the olecranon process
         - very important to examine whole upper extremity for evaluation of essex-lopresti lesion at wrist or associated fractures

- Radiographs:
    - it is essential to obtain radiographs both before and after reduction in order to asses for associated fractures (indicating
           a complex dislocations);
           - note the radial head avulsion frx, seen in this example

- Reduction of the Posterior Dislocation:

- Post Reduction Radiographs and Assessment of Stability:
    - generally the elbow will be stable in 90 deg or more of flexion;
    - the question is whether the elbow will be stable upto 30 deg flexion;
    - if instability occurs in 30 deg of flexion, then place forearm in maximum pronation which maximizes the stress on the
           MCL which reduces  posterolateral subluxation;
           - if there is increased stability in pronation, then the elbow should be placed in a cast brace with the elbow in pronation;
    - after clinically determining that the reduction will not be lost in 30 deg of flexion, obtain a portable lateral and AP radiograph;
    - look for joint widening, joint irregularity, or malalignment;
    - in difficult cases, flouroscopy can be used;
    - in cases of simple dislocation, persistent instability as the elbow is extended may indicate interposition of soft tissue or an
              osteochondral fragment;

- Non Operative Treatment:
    - stable articulation will allow for early flexion & extension if valgus stress is prevented after reduction;
    - no one has demonstrated a benefit from operative repair of MCL in simple dislocations;
    - best Rx results are obtained w/ early protected ROM begun before 2 wks;
            - if there is increased stability in pronation, then the elbow should be placed in a cast brace with the elbow in pronation;
    - final clinical outcome for simple dislocations of the elbow is dramatically affected by the duration of immobilization;
            - recurrent dislocation is unusual;
            - mild loss of extension is common, prolonged immobilization over two wks is assoc w/ greater flexion contracture
    - reference: Simple elbow dislocation among adults: a comparative study of two different methods of treatment.

- Operative Treatment of Simple Dislocations:
    - redislocation of elbow w/ passive range of motion or redislocation in plaster implies severe valgus instability w/ rupture of both
            MCL & flexor forearm muscles;
    - under these circumstances, operative treatment is indicated;
            - repair of MCL may be attempted but is not guaranteed to restore stability;
            - consider use of a hinged elbow fixator, which will allow early range of motion as well as stability;
    - arthroscopy: when exam findings unconvincing, possibility of intra-articular lesion, and reveals radiohumeral joint laxity

- Management of Complex Elbow Dislocations:
      - dislocation w/ radial head frx
      - terrible triad

- Complications:
    - valgus instability:
           - patients will show a variable amount of MCL laxity which correlates with a worse clinical and radiographic result;
           - to maximize the stress on the medial collateral ligament, the forearm should be placed in full pronation, which
                    reduces the posterolateral subluxation;
    - posterolateral instability;
    - heterotopic ossfication
           - whether or not all patients with simple elbow frx dislocations should receive prophylaxis is a matter of controversy;
    - chronic dislocations:
           - in some cases, recurrent instability will be due to posterolateral instability;
           - management of untreated posterior dislocations of the elbow three or more wks after injury may require open reduction;
           - posterior approach: w/ lengthening of triceps, removal of  fibrous tissue, & possible K-wire stabilization has been
           - in the report by H. Moritomo et al. 1998, the authors discuss reconstruction of the coronoid process (w/ graft taken from the
                  olecranon) in order to help block dislocation;
                  - Reconstruction of coronoid process for chronic dislocation of the elbow. Use of a graft from the olecranon in two cases
