Anatomy of Carpal Tunnel


-  Discussion:
     - transverse carpal ligament, is a heavy band of fibers which runs between hamate & pisiform medially to scaphoid and trapezium laterally, and forms
            fibrous sheath which contains carpal tunnel anteriorly within fibro-osseous tunnel;
            - posteriorly, tunnel is bordered by carpal bones, and transports median nerve & finger flexor tendons from forearm to hand;
     - lies deep to palmaris longus & is defined by 4 bony prominences;
            - proximally, by pisiform & tubercle of scaphoid;
            - distally by hook of hamate & tubercle of trapezium;
     - from hamate & pisiform medially to scaphoid & trapezium laterally;
     - transverse carpal ligament, portion of volar carpal ligament, runs between these 4 prominences & forms fibrous sheath which contains
            carpal tunnel anteriorly w/in fibro-osseous tunnel;
     - posteriorly tunnel is bordered by carpal bones;

- Superficial Anatomy:
     - palmaris longus passes in front of flexor retinaculum to become continuous with the palmar fascia (see transverse carpal ligament);
     - palmar cutaneous branch of median nerve, which innervates skin over base of thenar eminence, arises short distance prox to flexor
            retinaculum, pierces deep fascia, & course superficial to the flexor retinaculum to reach the skin;
            - palmar cutaneous nerve of ulnar nerve course superficial to transverse carpal ligament & is not involved in CTS;
     - distal volar flexion crease crosses proximal end of scaphoid and pisiform & marks proximal edge of TCL;
     - references:
            - Safety of carpal tunnel release with a short incision. A cadaver study
            - Anatomy of neurovascular structures around the carpal tunnel during dynamic wrist motion for endoscopic carpal tunnel release


- Contents of Tunnel:
     - tunnel transports median nerve & finger flexor tendons (FDS, FDP , & FPL);
     - motor branch of median nerve in hand arises under or just distal to flexor retinaculum, & winds around distal border of retinaculum
            to reach hypothenar muscles and the lateral 2 lumbricals;
            - numerous variations in the branching have been described;
     - sensory branches innervate lateral three and 1/2 digits & palm of the hand;
     - references:
            - Anatomic variations of the median nerve in carpal tunnel release
            - Anatomical relationships among the median nerve thenar branch, superficial palmar arch, and transverse carpal ligament

- Guyon's Canal
      - ulnar nerve & artery do not pass thru tunnel but lie superficial to it in guyon's canal
      - pisiform is palpable & serves to mark entry, on its lateral aspect, of ulnar nerve and artery into the hand;

- Landmarks:
    - distal volar flexion crease crosses proximal end of the scaphoid & pisiform & identifies proximal edge of the transverse carpal ligament;
    - pisiform is palpable and just laterally will identify entry of ulnar nerve and artery into hand;
    - all thenar & hypothenar muscles, except the abductor minimi, originate partly from the transverse carpal ligament.
    - The Palmar Fat Pad Is a Reliable Intraoperative Landmark During Carpal Tunnel Release

    - Kaplan's Line:
           - Kaplan oblique line (line drawn from apex of interdigital fold between thumb and index finger, toward ulnar side
                   of hand, parallel w/ proximal palmar crease, & passing 4-5 mm distal to pisiform bone



The transverse carpal ligament. An important component of the digital flexor pulley system.

Transverse carpal ligament reconstruction in surgery for carpal tunnel syndrome: a new technique.

Anatomy of the flexor retinaculum.

Prevalence of anatomic variations encountered in elective carpal tunnel release

The Carpal Insertions of the Transverse Carpal Ligament
