- Indication for Closed Treatment:
- indications -- These are based on "personality" of the fracture as described by Nicoll EA (1964)
- he listed factors favoring union:
- displacement: if the fracture fragments on are or can be opposed to 25% in a transverse fracture, casting or bracing is permissible
- more than 50% initial frx displacement will significantly increase risk of loss of reduction and non-union, due to instability of frx;
- unstable frxs of tibia may be treated by closed reduction & casting, however, malunion may occur;
- displaced spiral fractures of the distal third of the tibia are especially difficult to manage with casting;
- refs: Fractures of the Tibial Shaft -- a survey of 705 cases
Spiral fractures of the shaft of the tibia. Initial displacement and stability of reduction..
- comminution: internal fixation necessary
- soft tissue wounds: open fractures should be treated by external fixation or intramedullary nailing
- infection: external fixation is used until prominent fixation can be accomplished.
- initial shortening of more than 2 cm is contra-indication for casting, since this amount of shortening would be expected w/ wt bearing (despite success of initial reduction);
- frx of tibia w/ intact fibula:
- is a relative contra-indication to functional bracing due to the propensity for angulatory deformity;
- often the tibia will fall into varus w/ distal frx and will fall into valgus w/ proximal frx;
- more than 50% cortical comminution or displacement more than 50% are significant risk factors for non-union;
- w/ stable frx avg time for union is 4 to 5 months, w/ range of 2 to 14 months;
- 1-2 % refrx & 1-2 % require bone graft for union;
- nonunion occurs in 2-5%, malalignment occurs in 3% to 8%, & shortening of more than 1 cm occurs in as many as 10% of patients;
- Radiographic Alignment (see: malunion of tibial frx)
- acceptable reduction:
- as noted by Milner SA (1997), there is a considerable amount of tibial shaft alignment variety, and therefore,
when there is a question of whether the reduction is acceptable, x-rays of the opposite leg should be obtained;
- this author noted that the mechanical axis of the normal tibia may not pass down the center of the medullary canal;
- ref: A more accurate method of measurement of angulation after fractures of the tibia..
- classic parameters:
- more than 50% of cortical contact;
- less than 5-10 deg of varus / valgus angulation when comparing tibial plateau to tibial plafond (some will not accept more than 5 deg of varus);
- less than 10-15 deg of anterior or posterior bowing on lateral film;
- less than 5 - 7 deg of internal or external rotation, varus or valgus;
- no more than 10-15 mm of shortening;
- Casting Technique:
- initial long leg cast be applied w/ knee in 0 to 5 deg flexion (more flexion will allow better rotation control of the fracture);
- note: application of well molded cast can dramatically increase compartment pressures;
- location for casting:
- office -- if the fracture does not need reduction in the patient can sit with the knee flexed to 90° over the table.
- emergency room --is sedation is needed and reduction can be obtained with minimal manipulation
- operating room -- if more sedation is needed or more manipulation is needed
- procedure for casting with minimal sedation
- patient is supported while sitting with the knee flexed 90° over the end of the table;
- gravity will often reduce the fracture;
- an assistant places his hands under the metatarsal heads to keep the ankle at 90° in neutral or slightly protonated position.
- surgeon may have to manipulate the fracture;
- well padded short leg cast is applied holding the fracture reduction;
- after the cast has partially dried, add soft roll and plaster to make it a long leg cast with the knee infive to 10° flexion;
- if the fracture is distal, the PTB cast with molding around the tibia condyles can be applied;
- be sure the bottom of the cast is molded to accommodate the walker;
- patient can use crutches and bear weight as tolerated;
- fracture is x-rayed weekly for two weeks, and then at six weeks postinjury.
- casting is done the same in hospital;
- position of ankle:
- w/ a recurvatum deformity, the foot should be placed in slight plantar-flexion;
- neutral dorsiflexion will increase frx recurvatum in an unstable frx;
- if fascial compartments are somewhat tight (but compartment syndrome is not present) consider placing ankle in slight flexion (between the resting and neutral position) as well as bivalving the cast;
- after 3-5 weeks, switch to short leg cast or a cast brace;
- there are some frx that are best left in above knee cast, such as frxs close to knee joint, and frx assoc w/ intact fibula;
- always consider the risk of DVT (especially in obese patients);
- DVT prophylaxis for frx trauma;
- Wt Bearing:
- there is a correlation between delayed wt bearing & delayed or non union;
- w/ stable frx, wt bearing is begun as soon as tolerated;
- usually between 7th and 14th day, pt achieves full wt bearing w/ crutches;
- weekly x-rays are required to confirm adequacy of reduction, then as callus forms, radiographs are taken every 2 to 3 weeks;
- when fully wt bearing, the pt may switch to canes as tolerated;
- w/ stable frx, above knee cast may be converted to below knee patellar bearing cast at 3-5 weeks;
- there are some frx that are best left in above knee cast, such as fractures close to knee joint, and frx assoc w/ intact fibula;
- cast modification:
- once partial fracture healing has taken place, consider functional brace or consider a below knee cast w/ dorsum of foot and ankle removed to allow ankle dorsiflexion;
- active dorsiflexion and plantarflexion stresses the tibia and produces displacements similar to wt bearing;
- Tibial Non Unions:
- ideally wt. bearing is begun no later than 6 weeks after injury;
- if delayed union is suspected in pt who has been non-wt bearing for 3-4 mo, wt bearing should be instituted, preferably in long leg cast;
- if fibula is intact or has healed, resection of 1-2 cm of fibula may improve loading of frx site & stimulate union;
- this will result in union of fairly high % of delayed unions;
- Outcome Studies:
- Sarmiento A (1967)
- Rx: w/ a patella tendon bearing cast
- 100 consecutive fractures managed by reduction and long leg cast immobilization for 2 to 4 weeks, then application of the PTB cast;
- all fractures united, with closed fractures uniting in an average of 13.6 weeks and open fractures in an average of 16.7 weeks;
- shortest time to union was 9 weeks with a type A fracture;
- longest time to union was 21 weeks with a type C fracture;
- shortening averages 7 mm w/ a maximum shortening of 2.2 cm;
- Sarmiento A, et al. (1989)
- 780 selected fractures treated w/ early wt bearing and PTB bracing;
- 97.5% union rate;
- 90% of patients had less than 1 cm of shortening;
- 2% of patients had varus or valgus angulation > 11 deg;
- 2% of patients had anterior or posterior angulation > 10 deg;
- 4% of patients needed to have bracing discontinued, loss of position
- best results in closed and low energy fractures;
- Casting Pearls:
- be sure to mold under the sole of the foot inorder to restore the normal arch;
- the plantar aspect of the cast should come up the MTP flexion crease;
