THR: Acetabular Reaming





- Patient Position:
    - ensure that patient has not rotated anteriorly, for this may allow acetabular component to be placed in retroverted position;
    - ensure that patient's torso is not tilted inferiorly (as can occur from a bean bag), as this can cause reaming in an
             excessive verticle position;


- Acetabular Exposure
    - an unobstructed view of the acetabulum is manditory;
    - ensure that femur is retracted anteriorly to allow passage of reamers;
          - if femur is inadequately retracted anteriorly, then it may force reamers posteriorly, and excessive
                   reaming of posterior column will occur;
    - carefully dissect the transverse acetabular ligament from its bony attachments anteriorly & post
          - keep the blade superfical, to avoid brances of obturator artery, which pass beneath it;


- Identification of Acetabular Floor


- Reaming Direction:
    - component anteversionadult femoral and acetabular anteversion, component insertion,
            and component position);
    - superior wall of the acetabulum is a slope that must be converted to a hemisphere;
    - reaming is directed more against the medial and posterior wall than towards the acetabular roof;
    - need to avoid plowing into the superior rim as larger reamers are used;
    - goal is to avoid translating the center of rotation laterally or superiorly;
    - usual goal is 20-30 deg of anteversion and 35-45 deg of abduction;
    - w/ pt in lateral recumbent position after incision is made, one finger is placed in sciatic notch & one finger on
            anterior superior spine;
            - w/ methylene blue, line is drawn on drapes between these 2 points;
            - one line was drawn between sciatic notch & anterior spine on the drapes and a 2nd orthogonal line was drawn and
                     flexed an additional 10 degrees;
    - w/ osteoarthritis: reaming is directed more centrally rather than peripherally;
    - protrusio:
          - in severe acetabular protrusio reaming procedure is more aggressive and is directed peripherally and not centrally;
                 - therefore larger reamers and a larger cup is used;



- Reaming Depth:
    - remember that the goal is to obtain near complete coverage of the acetabular component;
    - initial medialization:
           - central portion of acetabulum requires more reaming than periphery;
           - to avoid superior placement of acetabular component, initial reaming is directed more medially;
           - use true floor of acetabulum as marker for depth of reaming;
           - reaming to depth that obliterates this U shaped portion of acetabulum (fovea) usually converts the bony acetabulum to
                  hemisphere;
           - note that the fovea is often located posteriorly:
                  - hence initial medialization must be dead center rather than centered over the fovea;
                  - if initial medialization reaming is started too posteriorly, then subsequent reaming will follow a posterior path and may
                           ream out posterior wall;
           - initial reaming is done w/ instrument about 9 mm smaller than templated size;
           - as reaming nears floor of acetabulum, the subchondral bone will start to break up exposing cacellous bone;
           - take care not to penetrate the medial wall, unless controlled penetration is necessary to obtain sufficient cup
                    coverage (medial protrusio tech);
           - references:
                    - Benefit of Cup Medialization in Total Hip Arthroplasty is Associated With Femoral Anatomy
                    - Restoration of the centre of rotation in primary total hip arthroplasty
           - cautions:
                   - if more bone must be removed from inferior margin of acetabulum, note occurance of significant bleeding
                             from obturator artery
                   - dense sclerotic bone in one region of acetabulum may result in eccentric reamining and eccentric cup placement;
                   - a smaller reamer useful to remove small portions of sclerotic bone which is causing a malposition of the reamer;
                   - excess bone in inferior margin of acetabulum may later cause head of femoral component to become levered out of cup
                             superiorly during adduction;

    - peripheral reaming:
            - initial use of a large reamer can destroy the superior rim, necessitating a bone graft for adequate coverage;
            - hence sequentially larger reamers are used to effect a controlled and centralized expansion of the acetabulum;
            - w/ use of progressively larger reamers, one may find that transverse acetabular ligament is hypertrophic and must be excised to
                    allow larger reamers to enter acetabulum;
            - elimination of sloped roof of acetabulum;
                   - larger reamers are inclined firmly under the superior aspect of acetabular rim to ream the bone to a hemisphere from its
                            normal sloped anatomy;
                   - careful not to remove bone from the superior rim at this step;
                   - when reaming the "sloped roof", the reamer should not engage the superior acetabular rim (because the reamer is engaging
                            the more medial roof instead);
                            - once the reamer begins to engage the superior rim, theoretically the roof is now a hemisphere;
                   - this step is especially important when under-reaming by 2 mm because failure to contour the flattened roof of the
                            acetabulum will result in incomplete seating of the acetabular component; (consideration for oversized components:)
            - cautions:
                    - take care w/ use of a larger reamers as these can destroy superior rim, necessitating a bone graft for adequate coverage;
                            - surgeons gloved hand nearest to reamer exerts downward pressure (vector) so that the reamer does not skive upward;
                    - need to avoid damage to the posterior column w/ progressively larger reamers;
                    - w/ excessive anterversion the reamer will be directed into the posterior column and will "skive off" the anterior column;
                    - keep a slight anterior directed force on reamer so that it equally reams surfaces of anterior and posterior acetabulum;
    - reaming subchondral bone:
          - avoid reaming through the entire subchondral bone since this provides significant structural support;
          - try to preserve subchondral bone, esp in superior aspect & periphery of acetabulum, but deepening acetabulum to obtain full
                 seating of cup in bone takes precedence over preserving subchondral bone;
    - final reamer:
          - final reamer size is determined by complete contact between the reamer and the acetabular rim;
          - ensure creation of complete hemisphere:
          - reamer 2 mm less than the intended cup size needs to be reamed 2-3 mm deeper than the peripheral edge of acetabulum;
          - this helps ensure that the acetabulum is deep enough to fully encompass the cup;
          - ensure that this reamer does not ream out the superior rim;
          - consideration for oversized components:
          - assess quality of subchondral bone:
                 - sclerotic bone circumferentially intact;
                         - dense subchondral osseous surface which is underreamed may not allow the acetabulum to expand around the cup;
                         - w/ hard sclerotic bone which is circumferentially intact around acetabulum, then 2 mm underreaming may not allow
                                  proper seating of cup;
                         - reamer 1 mm less than intended cup size needs to be reamed 1-2 mm deeper than the peripheral edge of aceatabulum;
                         - this may partially disrupt ring of hard (inflexible) circumferential subchondral bone which will allow proper expansion
                                   of the acetabulum around the cup as it is being inserted;
                         - careful not to ream out the acetabular roof;
                 - soft bone, subchondral bone partially reamed, no circumfertential sclertic bone:
                         - consider underreaming by 2mm, or press the 1 mm undersized reamer without reaming or with minimal reaming;
                         - when under reaming by 1 mm or with soft bone, use the last reamers in reverse in order to expand the acetabulum (and
                                    compacting the underlying bone) w/o removing bone stock;
                         - consider prothesis with screws;

    - references:
          - The case for removing the subchondral bone plate in preparation of the acetabulum
          - The value of preoperative planning for total hip arthroplasty.

- Trial Shells: (acetabular component position)
           - reaming is complete when all cartilage has been removed, reamers have cut bone out to periphery of acetabulum, and
                    hemispheric shape has been produced;
          - trial shell that was either the same size as the final reamer or one size bigger is then inserted (depending on surgeon's goals);
          - note final position of the shell in relation to the anterior and posterior walls (ie acetabular component position)
          - look through the windows of the shell to make sure that there is a true deepened hemisphere (ensure that the superior roof is not
                  flattened or underreamed) which can block the compoent from fully seating;
          - consideration for oversized components:
                  - trial prosthesis is placed & evaluated for fit;
                  - if this trial shell can be buried down to its base with hand pressure, then next larger size of trial shell is inserted;
                  - optimal trial size will not "bottom out" with gentle tapping of the mallet;
    - final preparation:
          - after trial placement, acetabulum is further prepared by removing any remaining soft tissue & clearing out bone cysts;
          - fill cysts with reamed bone graft and apply reamer in reverse to help impact the graft;


- Component Insertion
       - acetabular component position
       - consideration for oversized components


- Case Example:
    - 35-year-old male w/ near anklyosed hip following a GSW to the hip;
    - preoperative films appeared to indicate that little or no medialization was necessary;
    - postoperative films, however, indicate that the cup was lateralized (hence, reaming was inadequate)
