Closed Suction Wound Dressings

 1) Reduction of Post Op Surgical Bleeding. Why is this important?

      Recent paper on hematoma formation after TKR concludes:

          "Patients who return to the operating room within thirty days after the index TKA for
            evacuation of a postoperative hematoma are at significantly increased risk  for the
           development of deep infection and/or undergoing subsequent major surgery. These
           results support all efforts to minimize the risk of postoperative hematoma formation
."

           Surgical treatment of early wound complications following primary total knee arthroplasty
           J Bone Joint Surg Am. 2009 Jan;91(1):48-54.

2) Basic Science of Post Surgical Bleeding

    * Study from 2013, that fibrinolysis (ie. bleeding) peaked 6 hours after end of surgery and maintained about 18 hours after
             surgery, as evidenced by an increase in D-dimers.
    * concluded that effective use of TXA needs to extend to 18 hours to be effective.
    * study did not take into account the need for lovenox or xarelto
    * by parallel reasoning, any attempts to reduce postoperative bleeding needs to extend at least to 18 hours and possibly beyond.

    Duration of postoperative fibrinolysis after total hip or knee replacement: a laboratory follow-up study.
    Thromb Res. 2013 Jan;131(1):e6-e11. doi: 10.1016/j.thromres.2012.11.006. Epub 2012 Nov 26.

3) What has been the traditional gold standard to adress postoperative bleeding?

      * For the Duke trained surgeons in the 1990s, the gold standard was the application of
                 acewrap compression dressings for knee and hip replacements (shoulder replacements
                 were less common).
     * the more bleeding meant the application of more ace wraps.
     * even though these dressings did stop bleeding, there was a high patient dissatsifaction rate
     * TKR patients would complain of:
                - excessive dressing tightness
                - difficult with PT (unable to bend knee)
                - blistering from shear against the ace wraps with CPM and PT ROM
                - unacceptable discomfort from resultant foot and ankle swelling
                - unable to assess blood on the dressng (one indicator of bleeding)
     * THR patients:
                - extreme difficulty for the doctors and nurses to apply these dressings
                - basically have to have the patient standing up with legs spread while
                        leaning forward with a walker
                - humiliating
                - same complaints as with TKR patients (too tight and ankle swelling)
                - usually contaminated with urine and stool at the upper edges after a day or two.
                - occurance of deep decubitus ulcers in the groin region
                - unable to assess blood on the dressng (one indicator of bleeding)
     * TSR patients:
                - spica compression dressings (across the shoulder) are rarely applied.
                - extreme difficult in keeping the dressing in place
                - same complaints as seen in the TKR and THR patients.
                - can't assess the wound for bleeding.
     * compression dressings seem to "Rob Peter to pay Paul."
                - good for the incision but bad for the surrounding tissues.








4) What is the value of negative compression dressings and what are the options?

        * without going into detail, the negative compression dressings have been shown to be
                  extremely effective in assisting postoperative incisional healing in countless peer
                  reviewed joutnal articles - with esstenially no safey issues in general orthopaedics.
                  - use in spine, vascular surgery (over blood vessels), abdominal surgery are another issue.
        * most of the basic science work was done in the late 1990s by Morykwas and co-workers
        * most of the reported literature regarding negative pressure dressings is clinical and it is
                  largely assumed that the basic science principles are similar.
                  - obviously there is no open wound bed to induce granulation tissue
                  - the compression / compaction of the dressing causes the skin, subQ tissue, and muscle on
                          either side of the incision to come together in firm - even opposition.
                  - downward compression of of the dressing with negative pressure has a similar effect as
                          a compression dressing - without the negative side effects.
        * Commericial Options:
                 - Prevena™ Incision Management System
                            - was available at Duke Raleigh, but dropped due to cost (480 dollars)
                            - provena (KCI) uses 125 mmHg of pressure based on the orginal wound vac research (open wounds).
                            - endless supply of clinical trials:
                                     Negative pressure wound therapy to prevent seromas and treat surgical incisions after total hip arthroplasty
                                     Incisional negative pressure wound therapy after hemiarthroplasty for femoral neck fractures - reduction of wound complications.
                                     Negative pressure therapy is associated with resolution of incisional drainage in most wounds after hip arthroplasty.
              - PICO Closed Suction Dressing:
                            - currently available and the cost is about 180 dollars.
                            - pico uses 80 mmHg of pressure which last for 7 days.
                            - adhesive dressing is more flexible than tegaderm
                            - probably best for TKR patients which require constant motion: reduced blister formation.
                            - remember there are 4-5 TKR patients for every THR (the later do not require constant
                                    motion (CPM), but can bleed more.
                           - endless supply of clinical studies;
                           - negatives: the negative 80 mmHg of pressure is not enough to control bleeding in many cases.
                                    - bleeding and repeated dressing changes are risk factors for infection (
JBJS 2009 Jan;91(1):48-54.)
                                    - painful for the patient and requires use of valuable nursing time.

       * Off the Shelf Options Using Wall Suction:

                 - when it comes to protecting our patients, we need to protect our rights to use clinical reasoning or
                         otherwise the commercial corporations and government will take them
                 - in a recent review of negative pressure dressings:
                         A total of 24 studies found to match the study inclusion criteria, 22 were considered to favor a
                         particular system (the other two were categorized as impartial).
                        Of the 24 studies, 19 had some form of manufacturer involvement.
                        Of the 19 that had some form of manufacturer involvement, 18 had outcomes that were deemed
                                beneficial to the involved manufacturer, whereas one was deemed to have an impartial outcome.
                        This study suggests that manufacturer involvement in these studies (regardless of level) correlates
                                with the outcomes being beneficial to the involved manufacturer in almost all cases
.
                        - The influence manufacturers have on negative-pressure wound therapy research.
                                Plast Reconstr Surg. 2014 May;133(5):1178-83

               - at least 19 clinical references including at least 3 clinical trials (off the shelf vs. commercial) indicating safety and
                       similar clinical efficacy:

                       - as an example from the University of Chicago:
                              A prospective randomized trial comparing subatmospheric wound therapy with a sealed gauze dressing and the
                                      standard vacuum-assisted closure device. (Ann Plast Surg. 2012 Jul;69(1):79-84)
                                      - A randomized prospective study of 87 patients (N = 45 in the GSUC arm and N = 42 in the VAC arm) was
                                        undertaken between October 2006 and May 2008. The study comprised patients with acute wounds resulting
                                        from trauma, dehiscence, or surgery.
                       - RESULTS: (off the shelf gauze using wall suction was just as good as the KCI provena)

                         Demographics and wound characteristics were similar in both groups. There were significant reductions in wound
                         surface area and volume in each group. In the GSUC group, the reductions in wound surface area and volume were
                         4.5%/day and 8.4%/day, respectively (P < 0.001 for both), and in the VAC group, this was 4.9%/day and 9.8%/day,
                         respectively (P < 0.001 for both). The reductions in wound surface area and volume were similar in both groups (P =
                         0.60 and 0.19, respectively, for the group-by-time interaction). The estimated difference (VAC - GSUC) was 0.4%
                        (95% confidence interval: -1.0, 1.7) for wound surface area and 1.4% (95% confidence interval: -0.7, 3.5) for volume.
                        The mean cost per day for GSUC therapy was $4.22 versus $96.51 for VAC therapy (P < 0.01) and the average time
                        required for a GSUC dressing change was 19 minutes versus 31 minutes for a VAC dressing change (P < 0.01). The
                        sum of pain intensity differences was 0.50 in the GSUC group compared with 1.73 for the VAC group (P = 0.02).
                       -  CONCLUSIONS:
                               GSUC is noninferior to VAC with respect to changes in wound volume and surface area in an acute care setting.
                               In addition, GSUC dressings were easier to apply, less expensive, and less painful.

                       - as another example from 2015:

                       The authors report a randomized controlled trial comparing the efficacy of the GSUC vs the VAC in securing STSG.
                       A prospective, randomized, controlled trial was conducted in 157 wounds in 104 patients requiring STSG from August
                       2009 to July 2012. All wounds were randomized to VAC or GSUC treatment and assessed for skin graft adherence/take.
                      At postoperative day 4 or 5, NPWT was discontinued, and the size of the graft and any nonadherent areas were measured
                      and recorded. Concomitant comorbidities, wound location, etiology, study failures, and reoperative rates were also
                      reviewed. In all, 77 and 80 wounds were randomized to the GSUC and VAC study arms. Patient demographics were
                      similar between both groups in terms of age, sex, comorbidities, etiology, and wound location. In all, 64 of 80 wounds in
                      the GSUC group and 60 of 77 wounds in the VAC group had full take of the skin graft by postoperative day 4 or 5 (P =
                      .80). The mean percent take in the GSUC group was 96.12% vs 96.21% in the VAC arm (P = .98). The use of NPWT in
                      securing STSG is a useful method to promote adherence and healing. This study demonstrates that a low-cost, readily
                      accessible system utilizing gauze dressings and wall suction (GSUC) results in comparable skin graft take in comparison
                      to the VAC device
                      Prospective randomized controlled trial comparing two methods of securing skin grafts using negative pressure wound
                               therapy: vacuum-assisted closure and gauze suction. J Burn Care Res.  2015 Mar-Apr;36(2):324-8.











     * Rational conclusions regarding use of Wall Suction and Off the Shelf Dressings:


       1) for straight forward orthopaedic procedures (where the dressing is not over blood vessels or nerves), use of wall suction is safe.
        2) off the shelf dressings are applied using aseptic technique, but it is understood that wall suction connections are not sterile
                 - neither are the provena nor pico suction units after they are handled
                 - back in the day, the standard was guaze and silk tape (the guaze was sterile but the tape was certainly not - usually dirty)
                 - the main risk of infection is bleeding and the need to repeatedly change the dressings in the early post op period.
        3) off the shelf negative pressure dressings have been used at Duke Raliegh and have been shown to be safe.
                 - closed suction dressings that team Wheeless has used since 2007 have been set at 150 mm of pressure and are
                         only prone to blister formation if CPM is used.
                 - higher pressure allows for more internal collapse and compression of the dead space and less bleeding.
                 - main need is to keep appropriate pressure until there is no increase in bleeding on the dressing.
                 - once the bleeding has ceased the "conventional settings can be used" (the PICO unit is connected to the PICO tubing)
                           - Duration of postoperative fibrinolysis after total hip or knee replacement: a laboratory follow-up study.

- References for Off the Shelf Negative Pressure Dressings (gauze and wall suction):

        Prospective randomized controlled trial comparing two methods of securing skin grafts using negative pressure wound therapy: vacuum-assisted closure and gauze suction.
               vacuum-assisted closure and gauze suction.
        Homemade” Negative Pressure Wound Therapy: Treatment of Complex Wounds Under Challenging Conditions
        Negative pressure therapy with off-the-shelf components.
        An improved alternative to vacuum-assisted closure as a negative pressure dressing in lower limb split skin grafting: a trial.
        Use of indigenously made negative-pressure wound therapy system for patients with diabetic foot.
        Low-cost Negative-pressure Wound Therapy Using Wall Vacuum: A 15 Dollars by Day Alternative
        Evaluation of low-cost custom made VAC therapy compared with conventional wound dressings in the treatment of non-healing lower limb ulcers in lower socio-economic group patients of Kashmir valley.
        Negative pressure wound therapy using gauze and foam: histological, immunohistochemical and ultrasonography morphological analysis of the granulation tissue and scar tissue. Preliminary report of a clinical study.
        Use of indigenously made negative-pressure wound therapy system for patients with diabetic foot
        Negative Pressure Wound Therapy
        Negative Pressure Wound Therapy for the Treatment of Infected Wounds with Exposed Knee Joint After Patellar Fracture
        Prospective randomized controlled trial comparing two methods of securing skin grafts using negative pressure wound therapy: vacuum-assisted closure and gauze suction.
        A prospective randomized trial comparing subatmospheric wound therapy with a sealed gauze dressing and the standard vacuum-assisted closure device.
        Suction dressings: a new surgical dressing technique.
        Suction dressings in total knee arthroplasty--an alternative to deep suction drainage.
        External suction drainage in primary total joint arthroplasties.
        Negative Pressure Therapy on Primarily Closed Wounds Improves Wound Healing Parameters at 3 Days in a Porcine Model
        Our Experience with a "Homemade" Vacuum-Assisted Closure System
        An improved alternative to vacuum-assisted closure (VAC) as a negative pressure dressing in lower limb split skin grafting: a clinical trial.



4) Pressure Settings:
      Is High Pressure Better Than Low Pressure For NPWT? (Review Article from Aug 2010)

      Morykwas and co-workers defined various parameters in the application of NPWT that remain the standard today.
      They utilized a porcine model and examined the effects of pressure and intermittent cycles versus constant pressure on blood flow,
      granulation tissue formation, bacterial load and skin flap survival.

      Up until recently, the use of NPWT in hospitals was virtually synonymous with the VAC therapy wound dressing system
      (KCI). More recently, Smith and Nephew introduced a similar wound dressing system, V1STA and PICO, which also uses
      negative pressure.
      For VAC therapy, KCI recommends a pressure setting of -125 mmHg for normal use in the majority of wounds.

      This recommendation was based on the original work by Morykwas and colleagues, who looked at negative pressures from
       0 mmHg to -400 mmHg in 25 mmHg increments.
      When they measured underlying blood flow with a Doppler, there was a bell-shaped curve response over a range of NPWT.
      The maximal flow was four times the baseline and occurred with -125 mmHg pressure.
      When the pressure was above -200 mmHg, blood flow began to decrease.

      Indeed, a number of reported clinical studies have used NPWT with higher pressures than the recommended -125 mmHg with good
      outcomes.
      Jeschke and co-workers combined NPWT with fibrin glue in order to hasten the take of Integra (Integra Life Sciences).
      The study found NPWT with pressure of -150 mmHg reduced the take period from an average of 24 days down to 10 days.
      Meanwhile, the success rate of Integra increased from 78 to 98 percent.

      - in another study from Eurpope using off the shelf dressings and wall suction from 2004, the authors noted excellent clinical results
             in knee replacement patienets:
             - study protocol involved an off the shelf closed suction dressing with pressure set at 400 mm Hg for the first 12 hours.
             - it makes sense that they did not report blistering formation from these high settings because usually there is minimal aggressive
                     ROM during the first 12 hours after surgery;
                     - Suction dressings in total knee arthroplasty--an alternative to deep suction drainage.

 5) Conclusions: What have we learned about improving patient care?


    * at the end of the day we either follow evidence based medicine or we do not

    * compression dressings are bad for the staff (time consumming and do not allow the dressing to be visualized)
    * compression dressings are bad for the patient (painful and interfere with PT)
    * dressings that do not control bleeding and those that require repeated dressing changes (PICO at 80) may increase risk of infection.
    * use of hospital wall suction has proven to be safe for general orthopaedic surigcal cases such as joint replacements.
    * there are a variety of ways that the PICO tubing can be connected to wall suction;
    * use of 150 mm Hg wall suction is expected to better control bleeding until POD 1, than lesser settings.
    * pressure may be applied for longer time periods for patients with continued bleeding (eg. patients that are on plavix + lovenox)
    * expectation that there will be less dressing changes (better for the nurses and the patient)
    * CPM and aggressive PT ROM exercises should be minimized while the 150 mm settings are required.
    * once it is clear that there is no active accummulation of bleeding on the PICO dressing, the battery unit can be applied.
    * using hospital suction will allow for longer use of the PICO battery unit (it runs for only 7 days) which is beneficial during the
             outpatient time period.
    * with less bleeding, there may be potential for less blood tranfusion and earlier discharge (better for the hospital and the patient)







































*****

          - a cheap alternative to the wound vac concept involves use of gauze, fenestrated drain, and tegaderm;
          - gauze is applied over the wound, followed by application of fenetrated drain, followed by more gauze;
          - tegaderm is applied, airtight, and the tubing is applied to wall suction at about 175-200 mm Hg;
          - advantages: the gauze contracts down (paradoxically like a pressure dressing), and the skin edges are pressed together (because of the dressing
                    contraction), so that the dressing often remains free of blood and often does not have to be changed during the post op period;








The Problem:
      Issues involved in postoperative wound care are multi-focal, complex, and are codependent.  One goal is to minimize postoperative bleeding and drainage, blister formation, hematoma formation, and wound breakdown.  All of these may lead to pain, stiffness, and infection.  A second goal includes the need for optimal function.  In the case of knee replacements, dressings must allow the knee a free range of motion without creating blistering from shear and in the case of hip replacements avoiding cumbersome hip spica dressings which interfere with bathing and hygiene.

      When I was in my residency we were taught the classic toe to proximal thigh compression dressing for knee replacements.  The joke was that you needed a separate operative dictation for this type of dressing since it was such an involved ritualistic process.  The benefits of this type of dressing were mainly avoidance of hematoma, but it risked peroneal palsy at the fibular neck, inhibited ROM, and risked significant blistering of the skin with aggressive flexion from shear stress.  Further, this type of wound dressing does not allow a specific amount of compression to be applied and does not allow quantification of wound drainage. Alternatively not using a compression type dressing leads to the serious risk of hematoma formation, which dramatically increases the risk of infection, as well as stiffness and pain.  Indeed a recent paper on hematoma formation after TKR concludes, "Patients who return to the operating room within thirty days after the index total knee arthroplasty for evacuation of a postoperative hematoma are at significantly increased risk for the development of deep infection and/or undergoing subsequent major surgery. These results support all efforts to minimize the risk of postoperative hematoma formation."

       To further highlight the importance of this issue, I would point out the findings of a recent academy podium presentation concerning the complications in super morbidly obese patients undergoing TKR. "Overall, there were 54 (40.6%) surgical complications and 15 (14.3%) medical complications including 2 perioperative deaths. Surgical complications included 20 knees with prolonged wound drainage, 4 knees with cellulitis or stitch abscesses, and 6 legs with residual neuropathy for a minor complication rate of 22.6%. There were 19 (14.3%) re operations/major complications including 9 irrigation and debridements with component retention, 6 resection arthroplasties for deep infection."

       When we combine the needs of a postoperative dressing we agree on the need for efficient evacuation of drainage fluid, wound compression that can be maintained at a specific level, allowance for ROM and function, ease of hygiene, minimal shear and blister formation, ability to assess and quantify the amount wound drainage, and to minimize the need for postoperative dressing changes (as early dressing changes can tear at the skin).

       The most logical answer for an optimal wound dressing was suggested to me several years ago when one of the KCI Representatives (wound vac company) suggested that the classic wound vac could be used as a postoperative dressing.  This dressing would address all of the aforementioned requirements including compression (as the sponge compresses over the skin, there is a pressure effect).  The only issue is the significant expense of this commercial system.  During this time, I reasoned that the same effect could be achieved with sterile gauze, a hemovac drain, and covering tegaderm, and otherwise the principles are the same.  Just as with a wound vac, the pressure is set between 125 and 150 mm, using hospital wall suction.  As it turned out a literature search turned out good clinical data in 4 journal articles to support this concept (using the exact same technique), and I have found that this approach minimizes wound problems, especially in my co morbid group of obese diabetic patients that are receiving lovenox (or other blood thinners).  In addition, in the vast majority of these patients, the initial postoperative dressing remains dry throughout the hospital stay and therefore does not need to be changed.

CR Wheeless MD
crw3@datatrace.com

As an addendum, the question has been raised as to whether hospital wall suction is reliable for this purpose and whether it could cause skin necrosis if there were significant fluctuations in the wall suction pressure.  I think that the answer to this is quite simple.  First, the most common use of wall suction would probably include nasogastric tubes on "low wall suction."  If there were major fluctuations in the suction, then we would expect to see problems in these patients noting the delicate nature of the gastric lining (as compared to skin). Second there are papers in the general surgery literature that discuss the use of low and high internal suction drainage of the subcutaneous space for mastectomies (with no problems), and finally there are two orthopaedic papers that discuss using wall suction pressures as high as 300 mm Hg without complications (ref).  I think that it is clear that hospital wall suction set at 150 mm Hg is quite safe for orthopaedic patients.

- References for external closed suction drainage dressings:
      - Suction dressings: a new surgical dressing technique.
      - Suction dressings in total knee arthroplasty--an alternative to deep suction drainage.
      - External suction drainage in primary total joint arthroplasties.
      - Incisional Vacuum-Assisted Closure Therapy
      - Role of Vacuum Assisted Closure (VAC) Device in Postoperative Management of Pelvic and Acetabular Fractures
      - Incisional Wound Vac in Obese Patients
      - Adult Reconstruction Application of an incisional vacuum sponge
      - Incisional vacuum-assisted wound closure in morbidly obese patients undergoing acetabular fracture surgery.
      - Negative pressure wound therapy to treat hematomas and surgical incisions following high-energy trauma.
      - The effect of incisional negative pressure therapy on wound complications after acetabular fracture surgery
      - Incisional Negative Pressure Wound Therapy After High-Risk Lower Extremity Fractures
      - Negative Pressure Therapy on Primarily Closed Wounds Improves Wound Healing Parameters at 3 Days in a Porcine Model
      - Negative pressure wound therapy to prevent seromas and treat surgical incisions after total hip arthroplasty
      - A Prospective Randomized Trial Comparing Subatmospheric Wound Therapy With a Sealed Gauze Dressing and the Standard Vacuum-Assisted Closure Device.
      - Closed Incision Management With Negative Pressure Wound Therapy (CIM): Biomechanics.
      - Evaluation of closed incision management with negative pressure wound therapy (CIM): hematoma/seroma and involvement of the lymphatic system.
      - Negative pressure wound therapy with off-the-shelf components
      - Use of negative pressure therapy on closed surgical incisions: a case series.
      - Incisional vacuum-assisted closure therapy.
      - A novel dressing for total knee arthroplasty
      Use of Negative Pressure Wound Therapy on Closed Surgical Incision After Total Ankle Arthroplasty.


Motivation for Negative Pressure Dressings:
     - same advantages as seen with VAC dressings for open wounds (intensity of healing response, reduction of edema, opposition of
                skin edges)
     - Prevena™ Incision Management System
                 - was available at Duke Raliegh, but dropped due to cost (480 dollars)
                 - provena (KCI) uses 125 mm of pressure based on the orginal wound vac research.
                           Negative pressure wound therapy to prevent seromas and treat surgical incisions after total hip arthroplasty
                           Incisional negative pressure wound therapy after hemiarthroplasty for femoral neck fractures - reduction of wound complications.
                           Negative Pressure Wound Therapy Is Associated With Resolution of Incisional Drainage in Most Wounds After Hip Arthroplasty
      - PICO:
              - currently available and the cost is about 180 dollars.
              - pico uses 80 mm of pressure (mostly used for TKR which require constant motion): reduced blister formation.

Off the Shelf Literature: (15 references demonstrating safety)

       1) for straight forward orthopaedic procedures (where the dressing is not over blood vessels or nerves), use of wall suction is safe.
        2) off the shelf dressings are applied using aseptic technique, but it is understood that wall suction connections are not sterile
                 - neither are the provena nor pico suction units after they are handled
                 - back in the day, the standard was guaze and silk tape (the guaze was sterile but the tape was certainly not - usually dirty)
        3) manufacturers will want to lead us to believe that their products are special and unique and the settings are essential for wound healing.
                 - The influence manufacturers have on negative-pressure wound therapy research.
        4) off the shelf negative pressure dressings used at Duke Raliegh.
                 - closed suction dressings that team Wheeless has used have been set at 150 mm of pressure and are prone to blister
                         formation if CPM is used.
                 - higher pressure allows for more internal collapse and compression of the dead space and less bleeding.
                 - main need is to keep appropriate pressure for about 16 hours:





Original Text by Clifford R. Wheeless, III, MD.

Last updated by Data Trace Staff on Tuesday, April 5, 2016 12:28 pm
